| | Part number |
REVO SFP2 kits | |
SFP2 combi kit #1 (A1 and A2 modules, single artefact)
| A-5764-0001 |
SFP2 combi kit #2 (single artefact, no modules)
| A-5764-0002 |
SFP2 combi kit #3 (A1 and A2 modules, triple artefact)
| A-5764-0003 |
SFP2 combi kit #4 (triple artefact, no modules)
| A-5764-0004 |
Single artefact kit (SFA1 and single artefact holding kit)
| A-5764-0072 |
Triple artefact kit (SFA1, 2, 3 and triple artefact holding kit) | A-5764-0073 |
SFP2 probe and modules
| |
SFM-A1 2 µm general purpose straight module (type A skid)
| A1-D-02C90D |
SFM-A1 5 µm general purpose straight module (type A skid)
| A1-D-05C90D |
SFM-A2 2 µm general purpose cranked module (type A skid)
| A2-D-02C90D |
SFM-A2 5 µm general purpose cranked module (type A skid)
| A2-D-05C90D |
SFM-B1 2 µm straight module with smaller skid for short lands (type B skid)
| B1-D-02C90D |
SFM-B1 5 µm straight module with smaller skid for short lands (type B skid)
| B1-D-05C90D |
SFM-B2 2 µm cranked module with smaller skid for short lands (type B skid)
| B2-D-02C90D |
SFM-B2 5 µm cranked module with smaller skid for short lands (type B skid)
| B2-D-05C90D |
SFM-B3 5 µm 90° module with smaller skid for pockets and grooves (type B skid)
| B3-D-05C90D |
SFM-B4 5 µm cranked module with smaller skid for reach into confined areas (type B skid)
| B4-D-05C90D |
SFM-B5 5 µm cranked module with smaller skid for reach into undercuts and grooves (type B skid)
| B5-D-05C90D |
SFM-C3 2 µm straight module for small bores (type C skid) | C3-D-02C90D |
SFM-C3 5 µm straight module for small bores (type C skid) | C3-D-05C90D |
SFM-D1 2 µm 90° module for extra reach (type D skid)
| D1-D-02C90D |
SFM-D1 5 µm 90° module for extra reach (type D skid)
| D1-D-05C90D |
SFM-E1 2 µm long straight module with 2-part skid (type E skid)
| E1-D-02C90D |
SFM-E1 5 µm long straight module with 2-part skid (type E skid)
| E1-D-05C90D |
SFM-E2 5 µm long straight module with 2-part skid (type E skid) | E2-D-05C90D |
SFM-G1 Grooved engine bores prepared for PTWA coating (type G skid) | G1-D-10C30C |
SFM-H1 automatic transmission valve bodies, minimum feature access (mm): Ø9 × 122 (max. depth) (type H skid) | H1-D-02C90D |
SFM-H1 5 µm automatic transmission valve bodies, minimum feature access (mm): 9 122 (max. depth) (type H skid) | H1-D-05C90D |
Accessories | |
SFH-1 surface finish module holder
| A-5764-0080 |
SFH-2 surface finish module holder
| A-5764-0081 |
SFA1 3.0 SIN artefact (SFA1 plate with UKAS certificate)
| A-5764-0060 |
SFA2 0.5 SIN artefact (SFA2 plate with UKAS certificate)
| A-5764-0061 |
SFA3 0.4 ST artefact (SFA3 plate with UKAS certificate)
| A-5764-0062 |
OFA optical flat artefact (* special product)
| A-5764-3142 |
Single artefact holder mounting kit. Contains: SFAH-1 single plate holder, rack adaptor, leg adaptor, fixings for all options, tools
| A-5764-0070 |
Triple artefact holder mounting kit. Contains: SFAH-2 triple plate holder, rack adaptor, leg adaptor, fixings for all options, tools
| A-5764-0071 |
TFP tip find probe kit (including TP20 LF mod, stylus, PL24 cable)
| A-5764-0063 |
MST module setting tool
| A-5764-0091 |
System storage box | A-5764-0090 |
